Applicable to all types of plaster and double-sided tape composite into a roll
1) Production speed: 50 m / min;
2) Product acceptance criteria: deviation around complex controllable range ≤ ± 0.5 mm;
3) Electrical Power : 3KW,380V, 50HZ
4) Production process is two-sided composite tape + middle layer of plaster to spend a laminated film composite.
The main technical parameters and configuration instructions:
1) selection servo motors system 0.75KW A2 series ;
2) selection of 8 inches color screen human-machine interface;
3) three-way automatic tension control with PID automatic adjustment;
4) Production speed stepless use AUTONICS encoder;
5) High quality automatic edge devices;
6) The whole of the cantilever wall rack, wall thickness 30MM, wallboard six-sided machining, there are 304 stainless steel plate on the furface in to meet the GMP clean’s demand;
7) Transmission gears are grinding teeth; accuracy of 4-5; increase in driving accuracy, reduction of noise.
